CME H2MIDI Pro: Compact USB Host & 2x2 MIDI Interface

Q: How many MIDI ports does the H2MIDI Pro have?
A: It features a 2x2 configuration: 2 MIDI Inputs and 2 MIDI Outputs via standard 5-pin DIN connectors, plus a high-speed USB Host port for your controllers.

Q: Does the H2MIDI Pro support Bluetooth MIDI?
A: Unlike the H4MIDI WC, the H2MIDI Pro does not have built-in Bluetooth MIDI. It focuses on high-speed wired connections (USB and 5-pin). If you need wireless, we recommend the H4MIDI WC or adding a WIDI Master.

Q: Can I merge two MIDI controllers into one synth?
A: Yes! Using the free configuration software, you can set the H2MIDI Pro to merge incoming MIDI data from both the USB host and a 5-pin input to be sent out to a single output.

Q: Is it "Plug and Play"?
A: For standard 1-to-1 connections, it works right out of the box. For more complex routing, merging, or filtering, you can easily customize the behavior using the H2MIDI Pro’s dedicated software.

Q: Do I need a computer to use it live?
A: No. Once the routing is configured, the H2MIDI Pro works entirely standalone. Just plug it into a USB power source, and your rig is ready to go.

• Technology: USB Host And Client, Both Compliant With USB MIDI Class (Plug And Play)

Connectors

• USB-A: 1x (Host)
• USB-C: 1x (Client)
• MIDI DIN Input: 1x 5-Pins
• MIDI DIN Outputs: 1x 5-Pins
• DC Power Socket: External 9V-500mA DC Adapter Not Included

LED Indicators

• LED Lights: 4

Buttons

• Function Button: 1x Button For Presets And Other Functions

Compatible Devices

• USB MIDI Client Devices: Class Compliant, Supports One External Hub With Up To 8 MIDI Devices Or Ports
• Computers: USB MIDI Host Devices
• Standard MIDI Devices: Including 5V And 3.3V Compatibility

Compatible OS

• Operating Systems: MacOS, IOS, Windows, Android, Linux And Chrome OS

MIDI Messages

• Supported Messages: All Messages In The MIDI Standard, Including Notes, Controllers, Clocks, Sysex, MIDI Timecode, MPE

Wired Transmission

• Performance: Close To Zero Latency And Zero Jitter

Power Supply

• USB-C Socket: Powered Via Standard 5V USB Bus Or Charger
• DC Socket: 9V-500mA (5.5mm x 2.1mm), Polarity Is Positive Outside And Negative Inside
• USB-A Power Output: Provides Power To Connected Devices (Maximum Output Current Is 500mA)

Configuration & Firmware Upgrade

• Software: Configurable/Upgradable Via USB-C Port Using HxMIDI Tool Software (Win/Mac/IOS/Android Tablets Through USB Cable)

Power Consumption

• Consumption: 281 mW

Size

• Metric: 75 Mm (L) x 38 Mm (W) x 33 Mm (H)
• Imperial: 2.95 In (L) x 1.50 In (W) x 1.30 In (H)

Weight

• Mass: 59 G / 2.08 Oz

• Compact USB MIDI interface with professional-grade functionality
• Powered by a future-ready 32-bit processor for fast, precise MIDI handling
• High-speed optocoupler ensures reliable MIDI input without data errors
• Accurate, jitter-free transmission of all MIDI messages including clock, sysex, MTC, and MPE
• Includes free HxMIDI Tools software for advanced routing, filtering, and remapping
• Supports both 5V USB and 9V DC power sources for flexible setup options
• Direct USB MIDI to 5-pin DIN connection without a computer in Simple Mode
• Expand Mode supports up to 8 USB MIDI devices with full bidirectional 5-pin DIN I/O
• Advanced Mode adds 2 virtual MIDI ports over USB-C for computer integration
• Customize Mode offers software-based configuration of MIDI routing, mapping, and filtering
• Smart Mode enables future expansion and customization based on user needs
• Ideal for guitar pedalboards with space-saving design and DC compatibility
• Supports 4 user presets with hardware switching, no OS required
• Designed for class-compliant USB MIDI devices, including keyboards, synths, and controllers
• Compatible with major operating systems including macOS, iOS, Windows, Android, Linux, and ChromeOS
• Near-zero latency and jitter-free wired MIDI performance
• Powerful enough to supply up to 500mA to connected USB MIDI gear
• Built by CME, a trusted name in MIDI technology with 30+ years of expertise
• Backed by an active global community of users and contributors
